WARN R35-S Powersports Winch

TYPE: Winches     SKU: 110030
WARN R-Series Powersports Winches offer reliable performance from a name you can trust. With capacities ranging from 2,500 lbs. to 6,000 lbs. —our highest capacity powersports winch ever — we offer something for every ATV, UTV, or even a small pickup or SUV. R-Series has the features you want, the power you need, and a price that won’t leave you stuck looking at lesser brands. (read more)
$379.99
DESCRIPTION

WARN R-Series Powersports Winches offer reliable performance from a name you can trust. With capacities ranging from 2,500 lbs. to 6,000 lbs. —our highest capacity powersports winch ever — we offer something for every ATV, UTV, or even a small pickup or SUV. R-Series has the features you want, the power you need, and a price that won’t leave you stuck looking at lesser brands.

  • BACKED BY WARN - Engineered in Oregon, built to WARN specs, and thoroughly tested for quality control.
  • WATERPROOF - IP67 waterproofing keeps the water, dirt, and debris out and reliability in.
  • DURABLE - Highly efficient and strong all-metal three-stage planetary gear train is built to last.
  • COMPACT DESIGN - Easy to install.
  • RELIABLE BRAKE - Automatic load-holding brake for excellent control.
  • SUPERIOR WARRANTY - 5-year mechanical warranty, 3-year electrical warranty, supported by a US-based customer service team.
FEATURES
  • Rated line pull (single line): R35, R35-S, 3,500lbs (1588kg)
  • Motor: 12V DC permanent magnet
  • Sealing: IP67 rated waterproof
  • Gear train: R35, R35-S, R45, R45-S, R60-S: 3-stage planetary
  • Fasteners: Zinc plated
  • Rope: R25-S, R35-S: 50’ x 3/16” (15m x 4.8mm) synthetic
  • Hook: Zinc plated
  • Fairlead: R25-S, R35-S, R45-S, R60-S: cast aluminum hawse
  • Primary Controls: R35, R35-S: handle-bar mounted rocker switch; dash-mounted rocker switch; remote socket harness
  • Remote control: R25, R25-S, R35, R35-S: sold separately
  • Brake: R35, R35-S, R45, R-45-S, R60-S: mechanical brake
  • Warranty: 5 years mechanical, 3 years electrical
  • Dimensions: R35, R35-S: length: 12.3” (312mm), height: 4.7” (120mm), width: 4.6” (117mm)
  • Mounting Bolt Pattern: R25, R25-S, R35, R35-S: 3” x 4.9” (76.2mm x 167.4mm)
PRODUCT FITMENT GUIDE
  • Universal
